Constant M-Type High Pass Filter Trainer

MOd : FT- ED129

The Constant M-Type High Pass Filter Trainer enables high-frequency filtering experiments from 500-1500 MHz, with 3 dB cutoff frequencies at 900 MHz for both low-pass and high-pass functions. It features a band stop at 900 MHz and a band pass at 70 MHz.
Coupled with a Function Generator and DC Power Supply, it produces various waveforms (sine, triangle, square, TTL pulse) with >10 Vpp amplitude and 50Ω impedance. The system offers precise frequency control and voltage outputs, making it ideal for exploring electronic filtering and signal processing.

Description

Description

Constant M-Type High Pass Filter
Trainer

Technical Specification :

Operation Frequency: 500-1500MHz.
Low-Pass-3DB Frequency: 900 MHz
High-pass-3db Frequency: 900MHz
Measurement of Frequency Responses
Operation Frequency: 500-1500MHz.
Band stop Center Frequency: 900 MHz,
Bandwidth: 200MHz,
Band pass Center Frequency :70MHz
Bandwidth:20MHz,
Function Generator & DC Power Supply Module:
Waveforms: Sine, Triangle, Square, TTL Pulse
Amplitude: >10 Vpp
Impedance: 50Ω ±10 percent
Duty Control: 30 percent ~ 60 percent Display: 6-Digit LED Display
Frequency Range: 10Hz to 100 kHz (4 Ranges), 100Hz to 1 MHz (4
Ranges)
Frequency Control: Separative Coarse and Fine Tuning
Constant Voltage Output: ±5V, ±12V
Variable Voltage Output: 0V ~ ±15V

Accessories :

Connecting Wire: 1 set
User Manual: 1
Standard Accessories

Others :
Origin Parts : China, Taiwan, Japan.
Manufacturing in Bangladesh.
Warranty: 01 year.
Installation, Testing.
Training.
