Advanced Smart Trainer Platform with Electrical Module Package for Smart Lab

Description

Advanced Smart Trainer Platform
with Electrical Module Package
for Smart Lab

Technical Specification :

1. Platform (Advanced)
Embedded OS-based smart learning platform ; Intel® CPU Atom
Processor;1.6GHz,800MHz FSB, 512KB L2 cache ;
2.1W ultra low-power system, FCBGA package ;
Hyper- threading and 45nm technologies ;
Ethernet, USB and Serial interface ;
Touch screen resolution: 800 x 480 ;
124-point connector to connect an experimental module ;
Integrated measurement board employing the3-core CPU ;
Installed measurement application software (OS: Microsoft Embedded) ;
Multilingual selection and smart touch user interface control ;
Audio and video control functions
2. Signal input (2-channel)
1) Oscilloscope
Impedance: 1MΩ/20pF ;
Max voltage: ±50Vp-p ; Bandwidth: 4MHz;
Sample rate: 40MS/sec;
ADC resolution: > 10bit ; Voltage
DIV:±10/5/2/1/0.5/0.2/0.1/50mV/20mV;
Time DIV: > 22 times 1us~10s ;
Trigger: Auto, Single, Stop Mode, Memory: Streaming to host.
2) Voltmeter & Ampere meter
Measurement: AC/DC voltage, current, power(VA);
Function:Mean value, Peak value, Peak-to-Peak value, Root mean
square(RMS) value ; Range: Auto & Manual Mode ( > 9step
100mV~50V)
3. Signal output (1-channel)
1) Function / Pulse / Arbitrary Generator
Impedance: 50Ω/200mA ; Amplitude: 200mVpp, 2Vpp, 20Vpp(-
Max. 20Vpp) ; Frequency: 0.1Hz – 1MHz ;
Range:0.1Hz/1Hz/10Hz/100Hz/1kHz/10kHz/100kHz (7-step) ;
Outputwaveform: Sine, Square, Triangle, Logic, DC Pos(+), DC Neg(-)
2) DC Source Range: 100mV, 1V, 10V ; Voltage Source: ±0 ~ 10V
4. Digital input (digital analyser / counter)
Number of channel: 16 (Int. +Ext .) ; Input voltage: TTL/CMOS
Max. voltage: 20V ; Frequency: 100kHz; Trigger mode: Low,
high, DC ; Memory: Streaming to host ; Function: BIN (2-bit), OCT
(8-bit),DEC (10-bit), HEX (16-bit)
5. Digital output (Signal generator / timer)
Number of channel: 16 (Int. +Ext.) ; Output voltage: TTL/CMOS
Output current: 3mA ; Max. voltage : ±15V ; Output frequency:100kHz ; Memory : Streaming to host ; Function: BIN (2-bit),
OCT (8-bit), DEC (10-bit), HEX (16-bit)
6. Relay output
8-relay COM, ; NO/NC (Normally Open/Closed) ; 24VDC / 1A
7. Variable power supply
1) 3-channel DC power
V1 voltage : DC 0 ~ ± 20V 1A ;
V2 voltage : DC 0 ~ ± 20V 1A ;
V3voltage : DC 0 ~ ± 20V 1A
2) 3-phase AC power
AC voltage : AC 14Vrms 1A (Resolution: 0.1V) ;
Frequency : 1Hz~ 150Hz (Resolution: 1Hz)
3) Advanced 3-phase power
8. Digital Multi meter
Voltage: DC 1V, 10V, 100V, AUTO
AC 700mV, 7V, 70Vrms, AUTO, 40Hz ~ 20kHz ;
Current: DC500mA, 2A, AUTO ;
AC 500mA, 2Arms, AUTO, 40Hz ~ 5kHz ;
Resistance: 100Ω,1kΩ,10kΩ,100kΩ,1MΩ,10MΩ, AUTO;
Capacitance: 10µ, 100µ, 10n, 100n, 1000n, AUTO ;
Continuitydiode: 1V, 10V
9. Fixed power supply
Fixed voltage: +3.3V/2A, +5V/2A, ±15V/500mA (Common)
10.Application software for measurement (installed in the main
unit)
1) Measurement control
All functions are directly connected to the equipment to
controland to set up I/O values identical to actual instrumentation devices.
Oscilloscope:
By setting the signal (voltage) value according to thetime setting
(22 values between 1us and 10s per time unit), you candisplay a
waveform graph for each of the two channels, Channel A(yellow) and Channel B (blue), and compare waveforms.
It providesXY (Lissajous’ figure) and trigger functions.
Power meter:
Calculation of wattage is possible through thevoltage input to
channel A and current of channel B.
Voltage & Ampere meter: can select a measurement mode
tomeasure voltage or current in two channels .There are
fivemeasurement modes: AV, |AV|, P, PP, and RMS.
Function generator:
It provides the function of selecting basicoutput signals
[sine/square/ triangle /logic/DC(+)/DC(-)].
Pulse generator:
The setting display window, voltage output leveland frequency
can be configured. It provides the function ofcontrolling and
adjusting the pulse output signal (unipolar/bipolar/short pulse)
and pulse width.
Arbitrary waveform generator:
It provides basic waveforms suchas sine wave, triangle wave,
and square wave provided by thefunction generator. It also
offers various types of other waveforms(All Sine, Half Sine,
Sin(X)/X, Cosine, Tangent, Up Ramp, DownRamp, Up Stair ,
Down Stair, and Noise).
DC source:
DC voltage can be generated in the range from -10Vto +10V.
The range selection helps increase accuracy at the time ofsetting
up the voltage.
Digital multi meter:
The user can select a range for measuringDCV (DC voltage),
ACV (AC voltage), DCI (DC current), ACI (ACcurrent),
short-circuit resistance (Beep), resistance, capacitance,diode
measurement

Accessories :
User manual.
Connecting Wire
Single Phase power cord.

Others :
Installation, Testing, and Training.
Warranty: 01(One) Year
Origin: China. taiwan, Japan,
Manufacturing: Assemble in Bangladesh.
