Description

Optical Fiber Trainer

Technical Specification :

Fiber Type: Single Fiber
Applicable Fibers:
SM (single mode)
MM (multi-mode)
DS (dispersion)
NZDS (non-zero dispersion)
BIF/UBIF
Average Loss:
0.02 dB (SM)
0.01 dB (MM)
0.04 dB (DS)
0.04 dB (NZDS)
0.02 dB (BIF/UBIF)
Return Loss: 9s / 6s (fast mode)
Typical Splicing Time:
250μm
600μm
900μm
2~3mm
3.5mm
Compatible Cable:
250μm
600μm
900μm
2~3mm
3.5mm
Fiber Diameter:
Cladding diameter: 80~150μm
Coating diameter: 100~1000μm
Image Display: High-performance 4.3 inch LCD
Battery Life: 1000 charging cycles
Electrode Life: Typical 3,000 times, and replaceable
External Interface: Mini USB
Result Record: Maximum 10,000 results
Heater Function: Automatic, support user-defined heating
mode, 0°C ~ 300°C adjustable
Power Supply:
Built-in lithium battery: 11.1V
AC/DC adapter input: AC 100-240V
Output: DC 13.5V / 5.0A
Following Accessories Will Be Supplied with the Splicer
Machine:
Chargeable Battery
AC/DC Adaptor
AC Power Cable
Tweezers
Cooling Tray
Carrying case
Fiber Strippers
Indoor Cable Stripper
Alcohol Bottle
Fiber Cleaver
Warranty Card
User Manual
OTDR Machine: Technical Specifications:
Optic fiber type: SM
LCD: 5 inch color LCD
Pulse width: 5ns~20us
Measurement time: 5s, 15s, 30s, 60s, 120s, 180s
Attenuation dead zone: 6m
Event dead zone: 3m
Distance accuracy: ± (0.8 + 0.55% * distance + sampling
resolution)
Data storage: Micro SD card, less than 16GB
Communication connector: Mini USB
Power: Lithium battery
Battery life time: Standby > 15 hours, measurement > 8 hours
Optical Power Meter: Technical Specifications:
Display Range:
1310/1490/1550/1625: -70 ~ +10 dBm
850/1300: -60 ~ +6 dBm
LED Light: SOS code output
Display Resolving Power: 0.01 dB
Calibrated Wavelengths:
850nm/1300nm/1310nm/1490nm/1550nm/1625nm
Optical Laser Source: Technical Specifications:
Working Wavelength (nm): 1310/1550
Output Power (dBm):
1310/1550: 0, -3, -6;
650: >0;
850/1300/1490/1625: -6 (error: ±0.2)
Optical Identifying Distance: 5km
Optical Interface: FC, SC, ST

Accessories:

Connecting Wire: 1 set
User Manual: 1 Nos
Standard Accessories

Others
Country of Origin: China
Manufacturing: Assemble in Bangladesh
Training
Warranty: 1 Year
