Description

Smart Home Automation Training Equipment

Technical Specification :

• HMI (Human Machine Interface) Part
• Edge Processor
• 3.4GHz Dual-core 64-bit Arm Cortex-A76 CPU
• 512KB per-core L2 caches, 2MB shared L3 cache
• LPDDMA-4267 SDKAM
• Dual-hand Card Line Wi-Fi8B Bluetooth 5.0 / Bluetooth Low
• Energy (BLE)
• F-inch TFT LCD
• IPS, Resolution 1024 x 600
• Capacitance Touch Screen
• 2MP Camera
• Resolution:100bp @30 fps Field of View120 degrees diagonal
• Home Block Part
• Auto Controller.
• Equipped with Dual Cortex-M33 or RISC-V Hazard 3 cores
• operating at speeds of up to 150MHz or more
• Features 520 kB of high-performance multi-bank SRAM
• Include external Quad-SPI flash with execute in place capability and 16kB of on-chip cache
• Decor
• Automatic Door Opening/Cusing
• Utilities door models to illustrate the opening and closing mechanism.
• Comprises 1x 5V Step Motor and 2x Feedback Switches
• Light -2x S4mm LED with feedback
• PIR Sensor-Direction range 10 to 80 cm or more
• Living Room:
• Curtian Copernted by a 12V Step Motor with 2 Feedback Switches
• FAN:5V 40mm FAN featuring RGB LED with feedback
• Light:2x S4mm LED with feedback
• Dust Sensor: Detects particle sizes from 0.3μ μm to 10μμm or more
• Measurement range for PMI 0/PM2.5/PM10:0 to 1.000μ μ/m or more
• TPHG Sensor – AI Environmental Sensor measuring VOC
• Temperature, Humidity, and Pressure
  Kitchen:
• GAS Director – Servo Motor with feedback Switch
• FAN:5V 40mm FAN with RGB LED with feedback
• Light -2x S4mm LED with feedback
• GAS Sensor – LPG and Methane Gas Detector
• Room – Windows / Security Read Switch
• FAN – 5V 40mm FAN with RGB LED with feedback
• Light-2x54mm LED with feedback
  Bathroom:
• FAN – 5V 40mm FAN with RGB LED with feedback
• Light – 2x54mm LED with feedback
  Others:
• Indicator: 12V RGB LED Strip for Indicate status
• Illuminance Sensor – Ambient Light detection sensor
  Shock Detection Sensor – 3-Axis Digital Accelerometer with +2 g/ +4 g/±8 g/±16 g sensitivity
  Software Specification
  IBM:
• Linux Kernel: aarch64 6.x
• Cloud & Edge: SSII Server, Blocz, Mosquito, S2M Bridge Server,
• AWS IoT
• GUI & Vision: PySlide, OpenCV
• Data Science & AI: Numpy, Marplotlib, Pandas, Scipy, Seaborn, Scikit-learn,
  Modipity:
• Security: SSI/TLS, MQTT, JFA, AES/KDF
• Pro plus Library (MB): Actuator & Feedback Lamp, Fan, Door
  Lock, Gas Breaker,
• Mood Lamp
• Sensor Object: Plc, Illuminance, TPHG, Dust, LPG Gas, 3-Axis
• Accelerometer, Open
• Detection
  Auto Controller:
• Embedded Runtime: REPL, Garbage Collection, PIO, LittleFS, CDC, MQTT
• Ali-Linear Regression, Logistic Regression, Perceptron, ANN
• Pro plus Library (Auto Controller)
• Actuator & Feedback Lamp, Fan, Door Lock, Gas Breaker, Mood Lamp
• Sensor Object: Plc, Illuminance, TPHG, Dust, LPG Gas, 3-Axis
• Accelerometer, Open Detection
• Machine Holder
• Quantity: 2
• MATERIAL: Compressed Wood punch with laminated melamine surface
• Dimension(warmon): 2440 X 270 X 750 mm
• Top surface around: 16 mm Laminated board 16 mm top visual with 1mm edging
• Color: Black, White, Wooden and etc
• Surface shall be serrated proof
• Base: Cold rolled Mill Steel tubular frame or Made with heavy-duty mild steel
• PVC leg stopper for floor protection
• Paint: Mid steel part protected with powder coating heat paint
• PVC coil handed with hot met glue to protect moisture gaining
• Phosphatized and Oven baked powder paint finish for anti-rest and longevity
• Anti-linesis chemicals added to make the board termite-proof Assembly

Accessories:

Single-phase power cord
4mm Banana Socket-1Set
User Manual

Others:

Brand: FaboTronix
Country of Origin: China, taiwan, japan.
Manufacturing: Assemble in Bangladesh
