Description
Specification:
IEC/NEMA Standard LT Panel using 1250A ACB (Adjustable) and Others Accessories as per IEC requirements for
LT Panel of Electric Sub-Station Supply of 16 SWG Sheet steel clad, dust and vermin proof, free standing, floor
mounting type, Complete Factory assembled 3- phase 4-wire 415V, 50 Hz indoor type Low Tension Switchgear panel,
having Suitable Earthing 1250A hard drawn electrolytic copper bus bar & comprising of followings
Panel Size: ( L 700 x W 550 x H 1700)mm Min.
Incoming :
01 No.1250A, 65kA, ACB with Shunt Opening & Closing Release, Under Voltage Trip Coil, Gear Motor, Door Frame,
Ultimate breaking capacity V AC 50/60 HzIcu (kA rms) at 440 V:42/50/66/130:
Rated service breaking capacity Ics (kA rms) at 440 V:42/50/130
Rated short-time withstand current V AC 50/60 Hz Icw (kA rms) 0.5 s:42/50/10,Position of neutral: Left/right
Compliant with IEC /EN 60947-2 Annex H or Equivalent.
03 Nos. Current Transformer, ratio : 800/5A With Suitable accuracy and burden .
01 Nos. Multi meter, 0 – 9999A
03 Nos. Indicating Lamp.
01 Set of Control Fuse.
01 Nos Panel Type Digital/Analog Ampare Meter, Volt Meter,
01 Nos. every device OVERCURRENT & EARTH FAULT RELAYS, Under-Over Voltage Relay, Phase Sequence Relay.
Country Origin of CT,PT & ACB : ACB must be made in Germany/Korea/Taiwan/Japan/USA/Sweden or IEC/
NEMA Certified equivalent standard of any country brand.
Terms and Conditions:
Front Door of LT Panel must be used transparent fiber/
glass door of easy visibility.
Must be use trolley wheel system as per weight of the panel.
LT Panel Size, Colling system, Busbar Size, Insulator’s and other
Accessories must be installed according to IEC guidelines.
Accessories:
Connecting Wire: 1 set
Standard Accessories
Others:
Country of Origin: China
Manufacturing: Assemble in Bangladesh
